Dual Amber/White (801D)

The JBA 200 series tailgate LED offers a sleek, factory fit option for lighting in the rear cargo area of your vehicle.

The LED is available in 2 output options of

– White (801W)

– Dual Amber/White (801D)

Both light output options have an available switch for mounting into the tailgate next to the light if desired. The 801W option is a 19mm push button switch with amber illumination and the 801D option is a 19mm 3 way toggle switch with amber illumination.

Key product information

• Wide 120 degree beam pattern for maximum light
• Light features CREE 10W LEDs
• Fascia made from CNC billet aliminium
• No drilling required to mount light (drilling only required if mounting optional switch next to light)
• Comes with DT quick connector

Important Fitting notes

• A seperate power wire will be required (4mm) to be run into the tailgate (does not pick up on any power in tailgate as no wires rated high enough for light or constant power)
• If using the optional JBA 3 way switch for the 801D Dual LED, a harness is provided with the kit option (801DKIT1) for ease of wiring and only one power wire is required to be run into the tailgate.
• If not switching through optional JBA switches, a relay will be required if switches being used are not rated to 5A or above and a 3 way switch or two sepearate switches are required for the 801D Dual LED as well as two power wires to be run into the tailgate
• 2007-2015 models with auto rear tailgate button requires modification to LED light. Please specify on order if you have this model and feature
